Mains Voltage/Frequency

The statistics were last updated Tuesday, 06 May, 11:54:31 EDT
`Hourly' Graph ( 5 Second Average)
Hourly Graph
Max Voltage  118.9 V, Hz (79.3%) Average Voltage  118.5 V, Hz (79.0%) Current Voltage  118.3 V, Hz (78.9%)
Max Frequency  60.1 V, Hz (40.1%) Average Frequency  60.0 V, Hz (40.0%) Current Frequency  60.0 V, Hz (40.0%)
`Daily' Graph (5 Minute Average)
Daily Graph
Max Voltage  120.1 V, Hz (80.1%) Average Voltage  118.9 V, Hz (79.3%) Current Voltage  118.3 V, Hz (78.9%)
Max Frequency  60.0 V, Hz (40.0%) Average Frequency  60.0 V, Hz (40.0%) Current Frequency  60.0 V, Hz (40.0%)
`Weekly' Graph (30 Minute Average)
Weekly Graph
Max Voltage  120.1 V, Hz (80.1%) Average Voltage  118.7 V, Hz (79.1%) Current Voltage  118.7 V, Hz (79.1%)
Max Frequency  60.0 V, Hz (40.0%) Average Frequency  60.0 V, Hz (40.0%) Current Frequency  60.0 V, Hz (40.0%)
`Monthly' Graph (2 Hour Average)
Monthly Graph
Max Voltage  119.7 V, Hz (79.8%) Average Voltage  118.3 V, Hz (78.9%) Current Voltage  118.5 V, Hz (79.0%)
Max Frequency  60.0 V, Hz (40.0%) Average Frequency  60.0 V, Hz (40.0%) Current Frequency  60.0 V, Hz (40.0%)
`Yearly' Graph (1 Day Average)
Yearly Graph
Max Voltage  119.1 V, Hz (79.4%) Average Voltage  118.1 V, Hz (78.7%) Current Voltage  118.9 V, Hz (79.3%)
Max Frequency  60.0 V, Hz (40.0%) Average Frequency  60.0 V, Hz (40.0%) Current Frequency  60.0 V, Hz (40.0%)
GREEN ### Voltage
BLUE ### Frequency
DARK GREEN ### Voltage peak
MAGENTA ### Frequency peak
